DMP PHBG 21mm Carburetor Manual Choke Minarelli AM6

The DMP PHBG 21mm carburetor is a replica of the Dellorto PHBG and offers an affordable solution for a wide range of 2-stroke engines. This version features a manual choke and is commonly used on Minarelli AM6 engines and other geared mopeds.

With its 21 mm venturi, this carburetor provides excellent airflow and quick throttle response. The round slide ensures smooth operation, making it suitable for both standard and mildly tuned engine setups.

The carburetor is equipped with a fuel inlet and an oil inlet, and has no vacuum connection. It features a 26 mm clamp/slip-fit manifold connection and a 38 mm air filter connection with M32 x 1.25 thread.

The manufacturer does not specify the installed main jet, idle jet or needle. This carburetor uses Dellorto small M5 (5 mm) main jets. Looking for different jet sizes? Browse our range of Dellorto 5mm main jets.

Specifications

• DMP carburetor
• Replica of the Dellorto PHBG
• Venturi: 21 mm
• Manual choke
• Suitable for 2-stroke engines
• Commonly used on Minarelli AM6 engines
• Engine connection: 26 mm
• Clamp/slip-fit manifold connection
• Air filter connection: 38 mm (M32 x 1.25)
• Round slide
• Main jet type: Dellorto small M5 (5 mm)
• Fuel inlet
• Oil inlet
• No vacuum connection
• Main jet: Unknown
• Idle jet: Unknown
• Needle: Unknown

This DMP PHBG 21mm carburetor is an affordable alternative to the genuine Dellorto carburetor and is suitable as a replacement carburetor or for performance-oriented 2-stroke engine builds.
